Technical Specifications

PART Nº	DESCRIPTION
1	Receiver Housing
2	Screw on Top of Receiver M3.5X8
3	Metal Seal of Opening Valve
4	Plastic Seal of Opening Valve
5	Open Firing Valve O-Ring 11.6x1.8
6	Opening Valve
7	Striker Plastic Cap Cover
8	Striker
9	Striker Spring 7x31x1
10	Striker Spring Buffer
11	Receiver Back Cover Plate
12	Receiver Back Cover Plate Allen Screw M5x14
13	Close Valve Spring
14	Plastic Close Valve
15	Close Valve Spring Stem
16	Close Valve Dynamic Wheel Adjust Spring
17	Close Valve Brass Housing Internal to Stem Seal
18	Close Valve Brass Housing Internal Seal Bottom 6.4x1.2
19	Close Valve Brass Housing Internal Seal Top
20	Brass Housing O-Ring 17x1.5
21	Close Valve Brass Housing
22	Close Valve Dynamic Pressure Adjust Threaded Screw Top
23	Striker Sear
24	Receiver Striker Sear Catch Pin Φ3.5x16
25	Sear Spring 5.3x13x0.5
26	Sear Catch
27	Receiver Trigger Arm Pin Φ3x17
28	Trigger Arm
29	Sear Catch Arm
30	Sear Catch Arm Pin Φ3x19
31	Trigger Tension Fine Adjust Spring 2.5x11x0.5 (x2 units)
32	Trigger Tension Fine Adjust Spring Base M5x10
33	Black Plastic Receiver Pin Cover 3.5x5.6
34	Black Plastic Receiver Pin Cover 3x4.6
35	Black Plastic Receiver Pin Cover 3x5.6
36	Safety Lever
37	Safety Lever Detent Ball (x2 units)
38	Safety Lever Detent Ball Spring 3x5.5x0.6
39	Safety Lever Adjust Tension Allen Set Screw M4x6
40	Receiver Pressure Gauge O-Ring 4x1.5
41	Receiver Pressure Gauge
42	Plastic Housing for Magazine Indexing Arm
43	Magazine Indexing Spring
44	Magazine Indexing Arm
45	Magazine Release Arm Tension Spring 2.9x30x0.6
46	Magazine Release Pusher
47	Metal Surround to Gauge and Magazine Release Arm Housing (24)
48	Magazine Release Arm Pin/Trigger Arm Housing Pin Φ2x8 (2,90)
49	Magazine Release Arm ( 17)
50	Magazine Release Assembly Allen Screw M3x8
51	Air Mag Index Assist Pin O-Ring 4.5x1.2
52	Air Mag Index Assist Pin Φ2.5X11
53	Brass Insert Screw O-Ring 4.5x1
54	Brass Insert Screw for Air Assist Magazine
55	Magazine Plastic Side Cover
56	Magazine Plastic Side Cover Allen Screw M3x6
57	Breech Seal O-Ring 11.5x1.5
58	Plastic Breech to Magazine Seal
59	Rubber Anti Vibration Receiver to Stock Buffer

Inside the box

Huben · Spare Parts for K1 · Diagram 2 of your choice.

Shipping

Shipping (UK)

Delivery in 3–10 working days.

Shipping costs depend on order value:

£0–£99.99 → £19.99
£100–£199.99 → £14.99
£200+ → £9.99

Payment & Security

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Spare Parts for Huben K1 Air Rifle · Diagram 2: Receiver/Main body

£847.00

Tax included.

Huben Spare Parts for K1 • Diagram 2 Receiver/Main Body includes key components for maintaining the structural integrity and performance of your K1 airgun. Precision-engineered for durability and seamless function
